The cover of machine and the parts which had touched with the production is made by stainless steel, the machine is beautiful and the product is sanitary. Moisture on the process, it leads the product uniformity, auto-counting, easy packing. There is stand by paper, it is easy to change the material, auto-stop when the material is use up.
Main technical parameter of making machine
Electrical source: 380V 50HZ
Total power: 13KW ( folding unit: 7KW, packing unit: 6KW )
Suitable material: wet strength paper, Spunlace non-woven fabric
Control system: PLC control system, Color touching screen
GSM material(gram per square meter):40~80 g/m²
Jumbo roll size: (160~200)×Ф1000 mm (W×D)
Single wipe unfolded size: 200×(160~200) mm (L×W)
Single wipe folded size: 100×(60~100) mm (L×W)
Folding speed: 300~500 pcs/min
packing speed: 40~60 packs/min
Another function: Punching unit, Roll type date printing unit
Final product size: (140~220)×(70~100)×(10~30) mm (L×W×H)
Machine size: (5150~9500)×1120×2100 mm (L×W×H)
Spare Part: Quantity：set
Slitting cutter: 120*40*8 2
Bottom cutter: 120*30*10 2
Insert paper cutter: 120*39*2 2
Nip paper cutter: 120*38*4 2
L 360*14: With keep off block 2
L 285*30: With keep off block 1
L Double size belt: 465-20 width 1
Flat belt: 900*40*1,8 with guide line 1
Flat belt: 790*120 1
Flat belt: 1050*40*1,8 1
Perforator Wheel 1
Thermoelectricity ring: ￠80*20mm 2
Galvanothermy Tube: 150*8 4
Thermo couple K model: 2
Sponge Belt: 1020*150*12 1
Flat belt: 600*25*3 1
Cutter: 150*25*4 2
Cutter drill: 150*25*4 1
Tool Box: 1
