LETHER PROCESSING ( PICKLED ) UNIT 2000 PIECES 24

Category
:
LETHER PROCESSING ( PICKLED )
Product Name
:
LETHER PROCESSING ( PICKLED ) UNIT 2000 PIECES 24
Product Description
:

Request a Bid
Required Field:20mt*10mt
Total Electricity Consumption:80 KW / 380 V/ 3 PHASE
Origin:TURQUE
Capacity:2000 unit 24 HEURE
Number of Employees:8 PERSON
Required / Air, Water and Fuel:6 Bar Air Presseure
Products
LEATHER CABINET (D15)
Max. dimensions : Max. diameter: 350cm, Max. length: 400cm
Main body: African Iroko wood, baked, hard.
Power group: Electric Motor + Hydraulic Coupling + Gear Box + Pinion Gear +
Large gear + Control Panel (Single or two speed)
Process applications: soaking, liming, chrome, paint.
Gearbox 40 Hp three-axis-. Power. The Pneumatic brake stops the desired place, thanks to the Cabinet gear.
• Wood Assembly Tropical, hard, chemical- resistant IROKO tree
• Casting parts, big gear 2600 mm. diameter coupled to revolved and nodular cast iron GG 26. frezede teeth open listing with content Pinion gear manufactured high-tin bronze.
• 1700 mm. diameter 170 mm and 200 mm. Cores are available in custom 22 percent and stars with DD drum shaft.
• Cabinet high tin bronze or drives the paste bearings.
• Cabinet door opens fully sealed, sideways. Stainless manufactured compounds.
• On the right or on the left, 2 filter system available.
• Cabinet manufactured compounds can link stainless bolt.
• Optional Circulation system.
LEATHER CABINET (D15)
Max. dimensions : Max.diameter :350cm, Max. length: 400cm
Main body: AfricanIrokowood, baked, hard.
Power group: Electric Motor + Hydraulic Coupling + Gear Box + Pinion Gear +
Large gear + Control Panel (Single or two speed)
Process applications: soaking, liming, chrome, paint.
Gearbox 40 Hp three-axis-. Power. The Pneumatic brake stops the desired place, thanks to the Cabinet gear.
• Wood Assembly Tropical, hard, chemical- resistant IROKO tree
• Casting parts, big gear 2600 mm. diameter coupled to revolved and nodular cast iron GG 26. frezede teeth open listing with content Pinion gear manufactured high-tin bronze.
• 1700 mm. diameter 170 mm and 200 mm. Cores are available in custom 22 percent and stars with DD drum shaft.
• Cabinet high tin bronze or drives the paste bearings.
• Cabinet door opens fully sealed, sideways. Stainless manufactured compounds.
• On the right or on the left, 2 filter system available.
• Cabinet manufactured compounds can link stainless bolt.
• Optional Circulation system.
LEATHER CABINET (D15)
Max. dimensions: Max. diameter: 350cm,
Max. length: 400cm
Main body: AfricanIrokowood, baked, hard.
Power group: Electric Motor + Hydraulic Coupling + Gear Box + Pinion Gear +
Large gear + Control Panel (Single or two speed)
Process applications: soaking, liming, chrome, paint.
Gearbox 40 Hp three-axis-. Power. The Pneumatic brake stops the desired place, thanks to the Cabinet gear.
• Wood Assembly Tropical, hard, chemical- resistant IROKO tree
• Casting parts, big gear 2600 mm. diameter coupled to revolved and nodular cast iron GG 26. frezede teeth open listing with content Pinion gear manufactured high-tin bronze.
• 1700 mm. diameter 170 mm and 200 mm. Cores are available in custom 22 percent and stars with DD drum shaft.
• Cabinet high tin bronze or drives the paste bearings.
• Cabinet door opens fully sealed, sideways. Stainless manufactured compounds.
• On the right or on the left, 2 filter system available.
• Cabinet manufactured compounds can link stainless bolt.
• Optional Circulation system.
TILTABLE HYDRAULIC POLYESTER PROPELLER  (MK-8)
Fiberglass-reinforced polyester body, with special material resistant to acids and bases yapımıştır mechanical effect.
 • Metal parts in contact with water, are stored with polyester.
 • The blades and tropical filter, are choosen from hard IROKO.
 •the functionning with double or single-speed motor with gear unit reinforcement.
• Steel stands on two legs hung playful way. Drain and refill with hydraulic pistons on either side can be performed easily.
• Electrical panel on the machine. Optionally, heat is added to the control system.
•the stagned water, during the wet process and at the end of Wet Process, is emptied by means of 2 pieces of hydraulic control valves through the control panel.
• Time, water, labor, is 75% more efficient compared with the concrete and wooden
HYDRAULIC FLESHING MACHINE (ET-3)
A contemporary new model,strong, fast and modern machine suitable forskinsof small ruminants animals such as sheep and goats(hairy-hairless). Powerful hydraulic system. Therefore, functionning impactless. 10 units for zig collector, 9 units for fur blades are mounted.
Working width: 1600 mm
Bladed Cylinder motor:18,5 kw
Hidraulic Pump motor: 7,5 kw
Grinding motor:0.37 kw
Total installed Power:26.37 kw
Net Weight:3400 kg
Dimensions ( LxWxH):3700*1000*1560 mm
